Deye Hybrid Inverter| SUN-7.5K-SG05LP1-US-SM2

Price
Availability Out Of Stock
14 Days Return Policy
Sales Tax Included
10 Years US Warranty

The Deye SUN-7.5K-SG05LP1-US-SM2 is a high-performance 7.5kW split-phase hybrid inverter designed for the North American grid, offering a robust 190A charging current and seamless 120/240V power for total residential energy independence.

Key Features

  • North American Split-Phase (120/240V) — True split-phase AC output for powering standard electronics and heavy 240V appliances directly.
  • Industry-Leading 190A Charging — Rapidly store solar energy during peak sun hours to ensure your family's demand is met at night.
  • Robust 12kW PV Input — Handles extreme solar oversizing to maintain peak performance year-round, even in low-light conditions.
  • 4-in-1 Versatility — Integrated solar inverter, MPPT controller, AC charger, and dedicated generator input port.
  • Extreme Scalability — Parallel up to 16 inverters for flexible energy solutions that grow with your property's needs.

Engineered for the US Grid

Fully compliant with UL 1741 SB and NEC 2020 standards. Features a color touch LCD, IP65 protection, and full remote monitoring via the Deye Cloud app. 10-year standard warranty.

UL 1741 SB & NEC 2020 Compliant

Deye Hybrid Inverter| SUN-7.5K-SG05LP1-US-SM2

R$ 0,00

Key Features

North American Split-Phase (120/240V) — Power Your Whole Home

Engineered for US households. This inverter provides a true 120/240V split-phase AC output for powering standard 120V electronics and heavy-duty 240V appliances.

120/240V Split Phase
UL 1741Certified
10msSwitching

Industry-Leading 190A Charging — Ultra-Fast Storage

Rapidly store solar energy. With 190A charging current, you can fill your battery bank quickly during peak sunshine for use when demand spikes at night.

190AMax Charge
190AMax Discharge
48VLV Battery

Robust 12kW PV Input — Maximize Your Harvesting

Supporting up to 12,000W of PV input power across two independent MPPT trackers, ensuring consistent energy production even in low-light conditions.

12000WMax PV Input
32A+32AInput Current
500VMax Voltage

4-in-1 Versatility — Solar, Battery, Grid & Generator

Integrated solar inverter, MPPT controller, AC battery charger, and dedicated generator input port for 100% energy security and flexibility.

Hybrid4-in-1
NEC 2020Compliant
6 PeriodTime-of-Use

Extreme Scalability — Parallel Up to 16 Units

Parallel up to 16 units for flexible energy solutions that grow with your property's needs, suitable for large estates or light commercial use.

16 UnitsMax Parallel
IP65Protection
NEMA3R Equivalent

Technical Specifications

Specifications for battery interface and management
Battery Type
Lead-acid or Lithium-ion
Battery Voltage Range (V)
40-60
Max. Charging Current (A)
190
Max. Discharging Current (A)
190
Charging Strategy
Self-adaption to BMS
Inputs
1
Solar panel input and MPPT specifications
Max. PV Input Power (W)
12000
Max. PV Input Voltage (V)
500
Start-up Voltage (V)
125
MPPT Voltage Range (V)
150-425
Max. Operating Input Current (A)
32 + 32
No. of MPP Trackers
2
Grid and load power output specifications
Rated Output Power (W)
7500
Rated Output Voltage
120/240V Split Phase
Rated Frequency (Hz)
60
Peak Power (Off-grid)
2x Rated, 10s
AC Output Current (A)
31.3
Grid Form
2L+N+PE
System performance and safety integrated features
Max. Efficiency
97.6%
MPPT Efficiency
>99%
Protection Rating
IP65 / NEMA 3R
Surge Protection
TYPE II (DC/AC)
Safety Compliance
UL 1741 SB, NEC 2020
Physical and environmental characteristics
Dimensions (WxHxD) mm
420 × 670 × 233
Weight (kg)
35.6
Operating Temperature
-40 to +60°C
Noise (dB)
<45
Cooling
Intelligent Air Cooling

DOWNLOADS & DOCUMENTS

DatasheetDatasheet

What's in the Box

  1. 1 Deye SUN-7.5K-US Split-Phase Inverter×1
  2. 2 WiFi Datalogger (Monitoring Dongle)×1
  3. 3 External CTs (Current Transformers)×2
  4. 4 Wall Mounting Bracket×1
  5. 5 Installation Hardware Kit×1
  6. 6 User Manual & Quick Start Guide×1

Frequently Asked Questions

It is a high-efficiency 7.5kW split-phase hybrid inverter designed for the North American market, providing 120V/240V power from solar, battery, and grid.

Yes. This model features a true split-phase output, allowing it to power standard 120V household items and large 240V appliances like dryers and well pumps simultaneously.

Yes. The unit is fully compliant with UL 1741 SB, IEEE 1547, and NEC 2020 requirements, including integrated AFCI and Rapid Shutdown control.

It features an industry-leading 190A charging current, enabling rapid energy transfer from your solar array to your 48V battery bank.

You can connect up to 12,000W (12kW) of total PV input power, allowing for significant oversizing to ensure performance in all seasons.

Absolutely. It has a dedicated generator input port and smart management logic to charge batteries or power your home directly from a generator during extended outages.

Yes. It features an IP65-rated enclosure (NEMA 3R equivalent), making it suitable for both indoor and outdoor installations.

The system supports paralleling up to 16 units, allowing you to build a system up to 120kW for large residences or small businesses.

Yes. It comes with integrated WiFi and Bluetooth for real-time monitoring of production and consumption via the Deye Cloud App.

Deye provides a standard 10-year warranty for the US market, ensuring long-term peace of mind for your sustainable energy investment.
