More power and flexibility for single-phase home energy storage. The Deye SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU series gives homeowners a modern low-voltage hybrid platform for solar self-use, backup power, and smart battery control.
One platform, seven output choices. Select from 3.6 kW to 10 kW output to match the home, PV array, and battery bank, while keeping the same single-phase SG05LP1 architecture with 2 MPPT and 40-60 V battery support.
Designed for stronger battery performance. Up to 210 A charging/discharging current depending on selected model, lithium BMS self-adaption, and 6 programmable battery time periods help move more solar energy into the times when the household actually needs it.
Built for retrofit, backup, and expandable projects. AC coupling can help upgrade compatible existing solar systems, diesel generator energy storage support adds resilience, and up to 16 units can operate in parallel for larger on-grid or off-grid systems.
Clean installation, confident daily operation. IP65 protection, colorful touch LCD, intelligent air cooling, WIFI / RS485 / CAN communication, and Type II surge protection on DC and AC sides make SG05LP1 a strong fit for modern residential ESS installations.
Official model identity and platform data (from datasheet). Columns: 10K / 12K.
Models
SUN-10K-SG02LP1-AU-AM3 / SUN-12K-SG02LP1-AU-AM3
Product Type
Single Phase Hybrid Inverter
Grid Connection Form
L+N+PE
Parallel Operation
Max. 16 pcs parallel for on-grid and off-grid operation
Ingress Protection
IP65
Warranty
10 Years
Battery-side data from the official datasheet (10K / 12K).
Battery Type
Lead-acid or Lithium-ion
Battery Voltage Range (V)
40-60
Max. Charging Current (A)
220 / 250
Max. Discharging Current (A)
220 / 250
Charging Strategy for Li-Ion Battery
Self-adaption to BMS
Number of Battery Input
1
Solar input data from the official datasheet (10K / 12K).
Max. PV access power (W)
20000 / 24000
Max. DC Input Power (W)
15000 / 18000
Rated PV Input Voltage (V)
500
Start-up Voltage (V)
125
MPPT Voltage Range (V)
150-425
Rated DC Input Voltage (V)
370
Max. Operating PV Input Current (A)
26+26+26
Max. Input Short-Circuit Current (A)
44+44+44
No. of MPP Trackers / Strings per MPP Tracker
3/2+2+2
AC-side data from the official datasheet (10K / 12K).
Rated AC Output Active Power (W)
9999 / 12000
Max. AC Input/Output Apparent Power (VA)
9999 / 12000
AC Output Rated Current (A)
43.5 / 52.2
Max. AC Output Current (A)
43.5 / 52.2
Max. Continuous AC Passthrough (A)
60
Peak Power (off grid)
2 time of rated power, 10 S
Power Factor Adjustment Range
0.8 leading to 0.8 lagging
Rated Input/Output Voltage/Range (V)
230/240 0.85Un-1.1Un
Rated Input/Output Grid Frequency/Range
50Hz/45Hz-55Hz
Grid Connection Form
L+N+PE
Total Harmonics Current Distortion (THDi)
<3% (of nominal power)
DC Current Injection
<0.5% In
Conversion efficiency from the official datasheet.
Max. Efficiency
97.60%
Euro Efficiency
96.50%
MPPT Efficiency
99.90%
Integrated protection from the official datasheet.
Integrated
DC Polarity Reverse Connection Protection, AC Output Overcurrent Protection, Thermal Protection, AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring, Overvoltage Load Drop Protection, Ground Fault Current Monitoring, Arc Fault Circuit Interrupter (optional), Power Network Monitoring, Island Protection Monitoring, Earth Fault Detection, DC Input Switch, DC Terminal Insulation Impedance Monitoring, Residual Current (RCD) Detection, Surge protection level
Over Voltage Category
TYPE II(DC), TYPE II(AC)
General and environmental data from the official datasheet.
Communication Interface
RS485/CAN
Monitor Mode
GPRS/WIFI/Bluetooth/4G/LAN (optional)
Operating Temperature Range
-40 to +60°C, >45°C derating
Permissible Ambient Humidity
0-100%
Permissible Altitude
2000m
Noise (dB)
<45 dB
Inverter Topology (solar/battery)
Transformerless / HF Transformer
Over Voltage Category
OVC II(DC), OVC III(AC)
Weight (kg)
35.6
Cabinet size (mm)
420W×670H×233D (Excluding connectors and brackets)
