Deye Hybrid Inverter | SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU

Preț
Output Power
Disponibilitate Stoc epuizat
3.6-10 kW single-phase hybrid inverter
48 V low-voltage battery
2 MPPT | Up to 16 units parallel

More power and flexibility for single-phase home energy storage. The Deye SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU series gives homeowners a modern low-voltage hybrid platform for solar self-use, backup power, and smart battery control.

One platform, seven output choices. Select from 3.6 kW to 10 kW output to match the home, PV array, and battery bank, while keeping the same single-phase SG05LP1 architecture with 2 MPPT and 40-60 V battery support.

Designed for stronger battery performance. Up to 210 A charging/discharging current depending on selected model, lithium BMS self-adaption, and 6 programmable battery time periods help move more solar energy into the times when the household actually needs it.

Built for retrofit, backup, and expandable projects. AC coupling can help upgrade compatible existing solar systems, diesel generator energy storage support adds resilience, and up to 16 units can operate in parallel for larger on-grid or off-grid systems.

Clean installation, confident daily operation. IP65 protection, colorful touch LCD, intelligent air cooling, WIFI / RS485 / CAN communication, and Type II surge protection on DC and AC sides make SG05LP1 a strong fit for modern residential ESS installations.

Deye Hybrid Inverter | SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU

0,00 lei

Comparison Table

FeatureCurrent Model
SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU
SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU-SM2-P
SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU-AM2-P
SUN-7/7.6/8/10K-SG05LP1-EU-SM2
SUN-7.5K-SG05LP1-EU-SM2-P
Output Power Range3.6-10 kW 3.6-10 kW 3.6-10 kW 7-10 kW 7.5 kW
Battery Platform40-60 V LV 40-60 V LV 40-60 V LV 40-60 V LV 40-60 V LV
Max Battery CurrentUp to 210 A Up to 210 A Up to 210 A Up to 210 A Up to 190 A
MPPT / Strings2 / 1+1 or 2+2 2 / 1+1 or 2+2 2 / 1+1 or 2+2 2 / 2+2 2 / 2+2
Max PV Access Power7.2-20 kW 7.2-20 kW 7.2-20 kW 14-20 kW 15.2 kW
Max PV Input Voltage500 V 500 V 500 V 500 V 500 V
AC Coupling RetrofitSupported Supported Supported Supported Supported
Generator Energy StorageSupported Supported Supported Supported Supported
Parallel OperationMax. 16 units Max. 16 units Max. 16 units Max. 16 units Max. 16 units
DisplayLCD LCD LCD Colorful touch LCD Colorful touch LCD
CommunicationWIFI / RS485 / CAN WIFI / RS485 / CAN WIFI / RS485 / CAN RS485 / RS232 / CAN RS485 / RS232 / CAN
ProtectionIP65 IP65 IP65 IP65 IP65

Technical Specifications

Core product identity, output range, battery platform, and installation profile.
Models
SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU
Product Type
Single-phase low-voltage hybrid inverter
Output Power Options
3.6-10 kW
Grid Connection Form
L + N + PE
Battery Platform
40-60 V low-voltage battery
Parallel Operation
Max. 16 units in parallel for on-grid and off-grid operation
Ingress Protection
IP65
Battery-side voltage, current, lithium BMS adaptation, and scheduling data.
Battery Type
Lead-acid or Lithium-ion
Battery Voltage Range
40-60 V
Max. Charging Current
90 / 120 / 135 / 175 / 190 / 190 / 210 A
Max. Discharging Current
90 / 120 / 135 / 175 / 190 / 190 / 210 A
Charging Strategy for Li-ion Battery
Self-adaption to BMS
Number of Battery Inputs
1
Battery Scheduling
6 time periods for battery charging/discharging
Solar input capacity, voltage limits, and MPPT/string configuration.
Max. PV Access Power
7.2 / 10 / 12 / 14 / 15.2 / 16 / 20 kW
Max. PV Input Power
5.76 / 8 / 9.6 / 11.2 / 12.16 / 12.8 / 16 kW
Max. PV Input Voltage
500 V
Start-up Voltage
125 V
MPPT Voltage Range
150-425 V
Rated PV Input Voltage
370 V
Max. Operating PV Input Current
13+13 A (3.6 kW) / 26+26 A (5-10 kW)
Max. Input Short-Circuit Current
17+17 A (3.6 kW) / 34+34 A (5-10 kW)
No. of MPPT / Strings
2/1+1 (3.6 kW) / 2/2+2 (5-10 kW)
AC power, current, passthrough, grid, and off-grid output data.
Rated AC Input/Output Active Power
3,600 / 5,000 / 6,000 / 7,000 / 7,600 / 8,000 / 10,000 W
Max. AC Input/Output Apparent Power
3,960 / 5,500 / 6,600 / 7,700 / 8,360 / 8,800 / 11,000 VA
Rated AC Input/Output Current
16.4/15.7 A, 22.7/21.7 A, 27.3/26.1 A, 31.9/30.5 A, 34.5/33 A, 36.4/34.8 A, 45.5/43.5 A
Max. AC Input/Output Current
18/17.2 A, 25/23.9 A, 30/28.7 A, 35.0/33.5 A, 38/36.3 A, 40/38.3 A, 50/47.9 A
Max. Continuous AC Passthrough
35 / 40 / 50 A
Peak Power (off-grid)
2 times rated power, 10 s
Rated Input/Output Voltage / Range
220/230 V, 0.85Un-1.1Un
Grid Frequency / Range
50/45-55 Hz, 60/55-65 Hz
Power Factor Adjustment Range
0.8 leading to 0.8 lagging
THDi
<3% of nominal power
DC Injection Current
<0.5% In
Efficiency values and integrated protection functions.
Max. Efficiency
97.6%
Euro Efficiency
96.5%
MPPT Efficiency
>99%
Integrated Protection
DC reverse polarity, AC output overcurrent, thermal, AC output overvoltage, AC output short circuit, DC component monitoring, anti-islanding, DC switch, insulation impedance detection, residual current detection, AFCI optional
Surge Protection Level
Type II DC / Type II AC
Communication, display, environmental, mechanical, and warranty data.
Communication Interface
WIFI, RS485, CAN
Display
LCD
Operating Temperature Range
-40 to +60 C, >45 C derating
Permissible Ambient Humidity
0-100%
Permissible Altitude
2000 m
Noise
<45 dB
Inverter Topology
Non-isolated
Over Voltage Category
OVC II (DC), OVC III (AC)
Cabinet Size (W x H x D)
330 x 580 x 232 mm (excluding connectors and brackets)
Weight
24.9 kg
Type of Cooling
Intelligent air cooling
Warranty
5 years / 10 years depending on final installation site and warranty policy

DESCĂRCĂRI ȘI DOCUMENTE

SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU DatasheetDatasheet SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU User ManualUser Manual

What's in the Box

Deye SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU – invertor solar hibrid monofazat pentru stocarea energiei rezidențiale
  1. 1 Deye SG05LP1 single-phase hybrid inverterx1
  2. 2 Wall mounting bracketx1
  3. 3 Fastening screws / mounting accessoriesx1 set
  4. 4 Battery temperature sensorx1
  5. 5 User manualx1
  6. 6 Smart meter / CT accessoriesOptional
  7. 7 DataloggerOptional

Frequently Asked Questions

Deye SUN-3.6/5/6/7/7.6/8/10K-SG05LP1-EU combines 3.6-10 kW single-phase hybrid output, 2 MPPT, 40-60 V low-voltage battery support, and on-grid/off-grid operation for residential solar storage projects.

Battery compatibility covers lead-acid and lithium-ion options across a 40-60 V voltage range. Lithium BMS self-adaption helps simplify integration, and max charging/discharging current reaches 90 / 120 / 135 / 175 / 190 / 190 / 210 A depending on selected model.

The SG05LP1 platform uses 2 MPPT trackers. String configuration is 2/1+1 for the 3.6 kW model and 2/2+2 for 5-10 kW models, so installers can match PV strings to the chosen output power.

Yes. AC coupling can help retrofit compatible existing solar systems when the design, wiring, and commissioning are handled correctly.

Yes. Up to 16 inverters can operate in parallel for larger on-grid or off-grid systems, with multiple batteries in parallel when the full system is designed correctly.

Yes. Diesel generator energy storage support gives backup-focused installations another source of resilience during extended outages or weak-grid conditions.

IP65 ingress protection and intelligent air cooling support outdoor installation. Final placement, wiring, and protection must still follow the official manual and local electrical requirements.

Native interfaces include WIFI, RS485, CAN. With the optional Deye Smart Transmitter SUN-SMART-TX01, compatible CT and wireless energy-management accessories can also communicate via LoRa. Battery communication depends on the selected battery and system design.
